EFFORTLESS MODULARITY, STREAMLINED BUILDS
The toolless removal of all exterior panels and modular brackets provide easier access for installation and cable management. With a removable bottom dust filter, ensuring the system stays clean and efficient.
VERSATILE COMPATIBILITY, ULTIMATE CUSTOMIZATION
Unleash your creativity with the flexible compatibility A3-mATX without compromising on high-performance, large size components. The A3-mATX case accommodates a maximum CPU cooler height of 165mm and a 4-slot thick GPU with a maximum length of 415mm. Note that with a 25mm thick fan installed at the bottom, the GPU thickness will be limited to 61mm, allowing for only a 3-slot GPU. Additionally, when installing a radiator and fan combo, there will be no space for the GPU.
SPACE MAXIMIZED FOR COOLING
Maximizing the cooling capacity of this 26.3 liter case, 360mm AIO can be mounted to efficiently cool high-end components.
A DAN CASES COLLABORATION
Combining the design of Daniel Hansen from DAN Cases with LIAN Li’s manufacturing prowess, the collaboration brings the A3-mATX to life.
MODEL NAME | A3-mATX |
MODEL NO. | A3-mATX-WD WHITE |
CASE TYPE | MFF (Micro Form Factor) |
COLOR | White(Wood Edition) |
DIMENSIONS | (D) 443mm x (W) 194mm x (H) 321.5mm (D) 443mm x (W) 194mm x (H) 306mm(w/o feet) |
MATERIAL | Steel |
MOTHERBOARD SUPPORT | M-ATX/ITX |
EXPANSION SLOT | 4 |
I/O PORTS | 1 x Power Button 2 x USB 3.0 TYPE-A 1 x USB 3.1 TYPE-C 1 x Mic 1 x HD Audio |
RADIATOR SUPPORT | Top: 1 x 360/240mm Side: 1 x 360/280/240mm Bottom: 1 x 240mm (360mm with fan at the bottom) |
FAN SUPPORT | Top: 3 x 120mm Side: 3 x 120mm or 2 x 140mm Bottom: 3 x 120mm Rear: 1 x 120mm |
GPU LENGTH CLEARANCE | Max 415mm |
CPU HEIGHT
CLEARANCE |
Max 165mm |
PSU SUPPORT | ATX/SFX/SFX-L (Max 220mm) |
